TU01-PWR-01 Kikusui DC Power Supply New

TU01-PWR-01 Kikusui DC Power Supply New

$210
$210 $0
Shipping calculated at checkout.
Request a Quote
Estimated Delivery in
5 - 7
business days (based on availability)

🎓 Request a Quote To Get An EDU Discount

Login & Get 2% Back on Purchases
Login or Sign Up for Loyalty

Features:

  • Variable internal resistance function
  • LAN (LXI compliant) /USB/RS232C as standard interface
  • A virtual multi-channel bus (VMCB) function makes multi-channel operation more efficient
  • A wide range of voltage and current settings can be combined within its output power rating (3 to 4 times)
  • Supporting universal input voltage (85 V to 265 V)
  • CONFIG setting shortcut function and display (Up to three parameters can be registered.)
  • Setting preset memory function (3 combinations of settings for voltage, current, OVP, OCP, and UVL)
  • Bleeder (sink) can be turned ON/OFF, with an even stronger bleeder mode setting available
  • Output ON/OFF delay function
  • Soft start/stop function
  • Durable Performance Operating temperature guaranteed up to 50 °C (122
  • Sequence function (supports triggered synchronization)
View full details
More Details
Specifications
Manuals
Item/Model PWR801L PWR801ML PWR801MH PWR801H
Nominal input rating 100 Vac to 240 Vac, 50 Hz to 60 Hz, single phase
Input voltage range 85 Vac to 265 Vac
Input frequency range 47 Hz to 63 Hz
Current (TYP) *1 100 Vac 11.2 A
200 Vac 5.6 A
Inrush current 50 A or less
Power (MAX) *2 1120 VA
Power factor (TYP) *1 0.99 (input voltage: 100 V), 0.97 (input voltage: 200 V)
Efficiency (TYP) *1

75%
Output hold time *2 20 ms or more



Item/Model PWR801L PWR801ML PWR801MH PWR801H
Voltage display Maximum display 99.99 999.9
Display accuracy ± (0.2 % of reading +5 digits)
Current display Maximum display 99.99 9.999
Display accuracy ± (0.5 % of reading +8 digits)
Power display The PWR DSPL LED lights in red.
Maximum display 9999
Display accuracy Displays the result of multiplying the current and voltage. The display is toggled with the voltage or current display.

Model No

TU01-PWR-01

Condition

New

Manufacturer

Kikusui

Current

8 A

Voltage

30 V

Power

800 W

TU01 PWR01 E2
