DML301 B&K Precision DC Electronic Load New

DML301 B&K Precision DC Electronic Load New

$1,920
$1,920 $0
Shipping calculated at checkout.
Request a Quote
Estimated Delivery in
5 - 7
business days (based on availability)

🎓 Request a Quote To Get An EDU Discount

Login & Get 2% Back on Purchases
Login or Sign Up for Loyalty

Features:

The BK Precision DML301 DC Electronic Load Module populates one slot of the DML001 DC Electronic Load Mainframe to create a flexible system for testing a variety of power sources. The front panel interface allows for quick adjustments of voltage, current, slew rate, pulse width, and more.

Module Only - Mainframe Sold Separately

  • Number of Channels: 1
  • Input Voltage: 0 to 80V
  • Input Current: 0 to 60A
  • Input Power: 300W
  • Module Only - Mainframe Sold Separately
  • Populates one slot of DML001 Modular 2-Slot Programmable DC Electronic Load Mainframe (sold separately)
  • Modular system provides flexibility to test variety of power sources including multi-output DC power supplies, batteries, fuel cells, and photovoltaic arrays
  • Adjustable slew rate in CC mode, users can control rate or slope of change in current in transient response test
  • Ability to simulate loading behavior of typical LEDs for testing LED drivers
  • Configure common LED characteristics including operating resistance, forward voltage, and operating current
  • Safely discharge batteries with configurable stop conditions including voltage and time
  • Fast transient operation and sweep modes for dynamic load conditions
  • Sweep mode offers simple way to capture overshoot and undershoot of power supply by applying two configurable load levels at swept frequency
  • Maximum power point test determines maximum power provided by power supply and voltage/current corresponding to maximum power
  • Transient operation allows module to periodically switch between two load levels
  • Transient mode simulates varying combinations up to 25 kHz in CC mode
  • Highly configurable list mode (sequence mode) with 100 user-programmable steps
  • List mode programs can be set up to repeat up to 65,535 times or indefinitely
  • Automatic test modes enables execution of multiple test sequences
  • Constant current (CC), constant voltage (CV), constant resistance (CR), and constant power (CW) operating modes
  • 16-bit voltage and current measurement system provides high resolution
  • Remote sense compensates for voltage drops
  • Intuitive front panel interface offers independent analog control and monitoring of each module to quickly adjust key parameters
  • Instrument settings and test configurations can be saved directly to internal memory for quick recall
  • Comprehensive built-in protections and automatic power-on self-test ensure stable and reliable operation
  • Overcurrent (OCP), overvoltage (OVP), overpower (OPP), overtemperature (OTP), undervoltage (UVP), and reverse polarity protections
  • Includes LabVIEW drivers and operating software for generating and executing test sequences and data logging without source code writing
  • 3-year warranty protects instrument against manufacturer defects
View full details
More Details
Specifications
Datasheets
Manuals

Specifications

  • Number of Channels: 1
  • Input Voltage: 0 to 80V
  • Input Current: 0 to 60A
  • Input Power: 300W
  • CV Mode Range: 0 to 6V (Low), 0 to 16V (Medium), 0 to 80V (High)
  • CC Mode Range: 0. to 0.6A (Low), 0 to 6A (Medium), 0 to 60A (High)
  • CR Mode Range: 0.015Ω to 30Ω (Low), 0.3Ω to 600 kΩ (Medium), 1.5Ω to 3 kΩ (High)
  • CW Mode Range: 6W (Low), 30W (Medium), 300W (High)
  • Transient Mode Slew Rate: 0.00012 to 0.06 A/μs (Low), 0.0012 to 0.6 A/μs (Medium), 0.012 to 6 A/μs (High)
  • Transient Mode T1/T2: 20 μs to 10 ms
  • Transient Mode Minimum Rise Time: 10 μs
  • Dimensions (W x H x D): 3.4 in. x 5.6 in. x 21.7 in. (85 mm x 142 mm x 550 mm)

Model No

DML301

Condition

New

Manufacturer

BK Precision

DML301 B K Precision DC Electronic Load Datasheet
DML301 B K Precision DC Electronic Load New Manual
