80C11-CR4 Tektronix Optical Analyzer Used

Name: 80C11-CR4 Tektronix Optical Analyzer Used
Brand: Tektronix
SKU: tektro_80c11-cr4
Availability: OutOfStock

Product variants

check availability

Request a Quote

Features:

Highly Accurate ER Calibrated (Extinction Ratio) Measurement Option for Increased Repeatability and Transferability of the Measurement
30 GHz Optical Bandwidth Conformance Testing and Characterization for 10 Gb/s Telecom and Datacom Standards and FEC Rates
1 Integrated Clock Recovery supports All Current 10 Gb/s Standards or User-defined Rates from 9.8 to 12.6 Gb/s (CR4)

Share on

View full details

More Details

Specifications

Options

Datasheets

Applications:

High-speed Optical Communications Testing
Extinction Ratio and Q-factor Measurements
Eye-pattern and Pulse Shape Analysis
Relaxation Oscillation Testing
Optical Signal Analysis
Compliance Testing
NRZ, RZ, and Optical Duobinary Signal Characterization

Specifications:

Bandwidth (GHz): 30
Wavelength Range (nm): 1100-1650
Fibre Input (μm): 9
Mask Test Sensitivity (dBm): -9
Number of Channels: 1

The 80C11-CR4 module is a long wavelength (1100 to 1650 nm) multirate optical sampling module optimized for testing 10 Gb/s datacom and telecom standard rates at 9.953, 10.3125, 10.51875, 10.664, 10.709, 11.0957, 11.317, and 14.025 Gb/s. With its high optical bandwidth of up to 30 GHz (typical) it is well suited for general-purpose high-performance 10 Gb/s optical component testing. The 80C11 can be optionally configured with clock recovery options that can support any standard or user-defined rate in the continuous range from 9.8 to 12.6 Gb/s.

Model No

80C11-CR4

Condition

Used

Manufacturer

Tektronix

ER Calibrated , module will only work on mainframe with Windows XP and oscilloscope FW V 5.0 and up

Tektronix 80C07B 80C08C 80C10B 80C11 80C12 80C25GBE
