PWX750MLF Kikusui DC Power Supply New

PWX750MLF Kikusui DC Power Supply New

$2,420
$2,420 $0
Shipping calculated at checkout.
Request a Quote
Estimated Delivery in
5 - 7
business days (based on availability)

🎓 Request a Quote To Get An EDU Discount

Login & Get 2% Back on Purchases
Login or Sign Up for Loyalty

Features:

  • A next-generation, internet-enabled rack mounted power supply
  • A virtual multi-channel bus (VMCB) function that fully supports multi-channel operation
  • A thin and lightweight design with 1U height for increased rack-mounting efficiency
  • Voltage and current range can be varied within the rated power (the ratio of 3 times)
  • Rated output power: 750 W/1500 W. Rated output voltage: 30 V/80 V/230 V/650 V
  • PFC circuit of 0.99 (with 100 V) or 0.97 (with 200 V) at full load
View full details
More Details
Specifications
Manuals
Item/Model PWX750LF PWX750MLF PWX750MHF PWX750HF
Half rack size   PWX750ML
Nominal input rating 100 Vac to 240 Vac, 50 Hz to 60 Hz, single phase
Input voltage range 85 Vac to 265 Vac
Input frequency range 47 Hz to 63 Hz
Current (MAX) *1 100 Vac 10.5A
200 Vac 5.25A
Inrush current *2 70 A or less
Power (MAX) *3 1100VA
Power factor (TYP) *1 0.99 (input voltage 100 V), 0.97 (input voltage 200 V) 0.98 (input voltage 100 V), 0.96 (input voltage 200 V)
Efficiency *1 74 % or greater
Hold-up time for power interruption *3 20 ms or greater



Item/Model PWX750LF PWX750MLF PWX750MHF PWX750HF
Half rack size   PWX750ML
Voltage display Maximum display 99.99 (fixed decimal point) 999.9 (fixed decimal point)
Display accuracy ±(0.2 % of rdng +5 digits)
Current display Maximum display 99.99 (fixed decimal point) 9.999 (fixed decimal point)
Display accuracy ±(0.5 % of rdng +5 digits)
Power display *1   The PWR DSPL LED lights in red.
Maximum display 9999
Display accuracy Displays the result of multiplying the current and voltage
Operation display OUTPUT ON/OFF, CV operation, CC operation,Alarm operation, Remote operation (LAN operation),Key lock operation, Preset memory



Item/Model PWX750LF PWX750MLF PWX750MHF PWX750HF
Half rack size   PWX750ML
Rating Output voltage *1 30V 80V 230V 650V
Output current *1 75A 28A 10A 3.5A
Output power 750W
Voltage Setting range 0V to 31.5V 0V to 84V 0V to 241.5V 0V to 682.5V
Setting accuracy ±（0.05％of set+0.05% of rtg）
Line regulation *2 ±5mV ±10mV ±25mV ±67mV
Load regulation *3 ±5mV ±10mV ±25mV ±67mV
Transient response *4 1 ms or less 7 ms or less
Ripple noise *5 (p-p)*6 60mV 80mV 120mV 330mV
(rms) *7 8mV 8mV 25mV 60mV
Rise time Rated load 100ms
No load 100ms
Fall time *8 Rated load 100ms 150ms 250ms
No load 450ms 550ms 1500ms 3000ms
Maximum remote sensing compensation voltage (single line) 1.5V 4V 5V 5V
Temperature coefficient (MAX) *9 100 ppm/°C (during external control)
Current Setting range 0A to 78.75A 0A to 29.4A 0A to 10.5A 0A to 3.675A
Setting accuracy *10 ±（0.5％of set+0.1% of rtg）
Line regulation ±9.5mA ±4.8mA ±3mA ±2.35mA
Load regulation ±20mA ±10.6mA ±7mA ±5.7mA
Ripple noise *11 (rms) *7 150mA 65mA 30mA 15mA
Temperature coefficient (TYP) *9 100 ppm/°C

Model No

PWX750MLF

Condition

New

Manufacturer

Kikusui

Current

28 A

Voltage

80 V

Power

750 W
