PM2002 Amplifier Research RF Power Meter Used

PM2002 Amplifier Research RF Power Meter Used

Calibrations
Check Pricing
Request a Quote

Request a Quote To Get A EDU Discount

Login & Get 2% Back on Purchases
Login or Sign Up for Loyalty

Select option

Additional Features:

  • Frequency Range: 10 kHz-40 GHz, power head dependent
  • Power Measurement Range: -70dBm to +44dBm, power head dependent
  • Number of Channels: Two
  • Measurement Speed: 1 channel : 200 readings/sec.
  • 2 channels : 100 readings/sec.
  • Power Heads : Select from a large number of diode and thermocouple Power Heads. The linearity and frequency calibration factors for the heads are provided in an EEPROM contained in a Head Data Adapter shipped with the Power Head.
  • Dynamic Range: Up to 90dB with diode heads, 50dB with thermocouple heads.
  • Inputs: Rear panel HEAD connectors and rear panel IEEE-488 connector standard.
  • Outputs: Rear panel PWR/REF connector, 0dBm, 50 MHz.
  • Rear panel RECORDER BNC connector, 0 to 10V into 1mW. Output impedance is 9.09kW.
  • May be operated into 1kW or 1V fs
  • Emulation: HP437, HP438 and Boonton 4220A
  • Displays: Menu-driven 20 character x 4 line LCD display
Share on
View full details
More Details
Specifications
Manuals

The PM 2002 is a dual channel high performance power meter that features high speed measurement capability and wide dynamic range.

Model No

PM2002

Condition

Used

Manufacturer

Amplifier Research

Amplifier Research PM2002 PH2000 Operating & Service Manual
