AFG3011C Tektronix Arbitrary Waveform Generator Used

AFG3011C Tektronix Arbitrary Waveform Generator Used

$6,930
$6,930 $0
In Stock
Shipping calculated at checkout.
Calibrations
Request a Quote
Estimated Delivery in
5 - 7
business days (based on availability)

Request a Quote To Get A EDU Discount

Login & Get 2% Back on Purchases
Login or Sign Up for Loyalty

Features:

  • 1 Channel
  • 10 MHz Analog Bandwidth
  • 10 Mhz Output Frequency
  • 128K points Record Length
  • 2 K - 128 K: 250 MS/s Max Sample Rate
  • 14 bits Vertical Resolution
  • Amplitude up to 20 Vp-p into 50Ω loads
  • 5.6" display for full confidence in settings and waveform shape
  • Multi-language and intuitive operation saves set-up time
  • Pulse waveform with variable edge times
  • AM, FM, PM, FSK, PWM
  • Sweep and burst
  • USB connector on front panel for waveform storage on memory device
Share on
View full details
More Details
Specifications

Arbitrary Function Generator 1 Channel, 10MHz

Unmatched Performance, Versatility and Ease-of-Use

Today's designs are often complex, demanding a variety of stimulus signals during test. With 12 standard waveforms, arbitrary waveform capability, and signal impairment options, the AFG3000 Series Arbitrary / Function Generator supports a wide range of application needs with one instrument. Best-in-class performance ensures signals are accurately reproduced. A large display and 25 shortcut keys make the AFG3000 Series Arbitrary / Function Generator both easy to learn and easy to use.

Superior Performance and Versatility

Users can choose from 12 different standard waveforms. Arbitrary waveforms can be generated up to 128 K in length at high sampling rates. On pulse waveforms, leading and trailing edge time can be set independently. External signals can be connected and added to the output signal. Dual channel models can generate two identical or completely different signals. All instruments feature a highly stable time base with only ±1 ppm drift per year.

Intuitive User Interface Shows More Information at a Single Glance

A large screen shows all relevant waveform parameters and graphical waveshape at a single glance. This gives full confidence in the signal settings and lets you focus on the task at hand. Shortcut keys provide direct access to frequently used functions and parameters. Others can be selected conveniently through clearly structured menus. This reduces the time needed for learning and re-learning how to use the instrument. Look and feel are identical to the world's most popular TDS3000 Oscilloscopes.

ArbExpress Software Included for Creating Waveforms with Ease

With this PC software waveforms can be seamlessly imported from any Tektronix oscilloscope, or defined by standard functions, equation editor, and waveform math.

Model No

AFG3011C

Condition

Used

Manufacturer

Tektronix-3

Frequency

10 MHz
