Teledyne LeCroy WaveSurfer 3000z & 4000HD Oscilloscopes

Two Powerful Paths to Deeper Signal Insight

Why Choose The WaveSurfer?

Engineered for precision, versatility, and usability, the WaveSurfer line delivers high-fidelity signal capture, advanced analysis tools, and intuitive control. Whether you’re debugging embedded systems, validating power rails, or tracking down digital anomalies, there’s a model that fits your needs and budget.  For a limited time these units come with a Mixed Signal Probe and analysis software for FREE!

Choose Your Powerhouse

 Model Key Specs & Highlights Ideal For
WaveSurfer 3104Z
  • 10.1” capacitive touch display
  • 100 MHz to 1 GHz bandwidth options (100, 200, 350, 500, 1 GHz)
  • Up to 4 GS/s sample rate (2 GS/s on 4 channels) and up to 20 Mpts memory (at 2 channels)
  • Rich feature set: MSO (16 digital channels), built‑in function generator, robust triggering / protocol decode, fast waveform updates, mask testing, history / waveform playback, anomaly detection, remote/network options, etc.
 Engineers needing flexible performance across analog and mixed‑signal domains, a versatile oscilloscope for embedded system debug, power envelope work, etc., where a solid, proven toolset is required with manageable cost
WaveSurfer 4000HD
  • 12‑bit HD4096 resolution with always‑on high vertical resolution
  • 1 GHz bandwidth, up to 25 Mpts record length
  • 12.1” 1280×800 capacitive touchscreen display
  • Mixed‑signal option (16 digital channels)
  • Extensive probe support: high‑voltage differential, current probes, power‑rail probes, etc.
  • Built‑in tools for protocol trigger & decode, power analysis, anomaly detection, smart user interface (MAUI / OneTouch)
 Users who need the highest fidelity signal detail (e.g. power integrity, power rails, clock analysis, sensitive embedded / analog / mixed signals), longer captures, and state‑of‑the‑art workflow tools for precise measurements.

Feature Highlights

  • Touchscreen UIs
    Both series offer capacitive touch displays (10.1" for 3000z; 12.1" for 4000HD) for immersive waveform viewing and easier, more natural interaction.

  • Deep Memory & High Sample Rates
    Vital when capturing rare events or observing long signal behavior. The 3000z delivers up to 20 Mpts in select modes; the 4000HD pushes even further.

  • Mixed Signal & Protocol Insight
    Serial bus trigger & decode, logic channels (MSO), and protocol overlays help you not just see what the electrical waveform is doing, but understand what higher‑level data / logic is being carried.

  • Power & Embedded System Tools
    From probing power rails, FFT / spectrum options, to specific software modules for power loss, device behavior, and embedded serial buses—both lines have strong options. The 4000HD especially is positioned for power / clock / noise sensitive scenarios.

Which One’s for You?

 If you care most about... WaveSurfer 3104z WaveSurfer 4000HD
Top‑notch vertical resolution & capturing small signal detail
✓
High bandwidth + deep memory ✓ ✓
Mixed signal with digital/analog leverage ✓ ✓
Tight budget but solid performance ✓ ✓
Power integrity, clock jitter, low‑voltage rails
✓
FREE MIXED SIGNAL PROBE ✓ ✓
FREE ANALYSIS SOFTWARE ✓ ✓
