• TTR506A Tektronix Network Analyzer
1 1
Used
Compare
lab tested

TTR506A Tektronix Network Analyzer Used

TTR506A Tektronix Network Analyzer Used

Calibrations
check availability
Request a Quote
Login & Get 2% Back on Purchases
Login or Sign Up for Loyalty

Features:

  • USB Vector Network Analyzer, 100 kHz to 6 GHz
Share on
View full details
More Details
Specifications
Datasheets

Legendary support and quality meets ease-of-use and affordability. The Tektronix TTR500 series 2-port, 2-path VNA is our latest breakthrough - an unmatched combination of measurement performance and convenience. Get the power to make everyday measurements with the accuracy and confidence you expect from Tektronix, all without breaking your budget.

Key performance specifications:

  • 100 kHz to 6 GHz frequency range
  • > 122 dB dynamic range
  • -50 to +7 dBm output power
  • < 0.008 dB RMS trace noise

Key features

  • Full 2-port 2-path S-parameter measurement (S11, S21, S12, S22) in a variety of formats.
  • Complete vector network analysis capability with Tektronix VectorVu-PC™ software.
  • Built-in bias tee accessible on both ports to bias active devices.
  • Application programming interface (API) for Microsoft Windows environment and LabView driver.
  • Robust SCPI command interface (compatible with current VNA models) to optimize code migration.
  • Touchstone file support (import/export) for use with Electronic Design Automation (EDA) simulation tools.
  • Offline simulation mode for analysis of S-parameter files when disconnected from the instrument.

Applications

  • Antenna matching and tuning
  • RF component design and validation
  • Education

Benchtop performance at a fraction of the cost

The TTR500 offers industry-leading price and performance. With more than 122 dB dynamic range and less than 0.008 dB RMS trace noise, the TTR500 has performance similar to expensive, conventional benchtop VNAs.

Model No

TTR506A

Condition

Used

Manufacturer

Tektronix

Tektronix TTR500 Series
Compare All Models
