9814-220V BK Precision AC Source New

9814-220V BK Precision AC Source New

$4,250
$4,250 $0
Shipping calculated at checkout.
Request a Quote
Estimated Delivery in
5 - 7
business days (based on availability)

Request a Quote To Get An EDU Discount

Login & Get 2% Back on Purchases
Login or Sign Up for Loyalty

Features:

  • 0 to 300 V, low distortion AC power source with 500 VA and 1000 VA models
  • Output frequency adjustable from 45 Hz to 500 Hz
  • Displays Vrms, Irms, Ipeak, frequency, power factor, crest factor, and elapsed time measurements
  • Comprehensive protection including overvoltage (OVP), overcurrent (OCP), overpower (OPP), and overtemperature (OTP)
  • 24-bit color 4.3” LCD screen
  • Built-in PLD and dimmer simulation
  • Pre-compliance testing for voltage dips and frequency simulations according to IEC61000-4-11 / 4-14 / 4-28
  • USB (VCOM) and RS232 interfaces provided standard
  • Switch between manual output control, list program mode, and continuous mode
  • LabVIEW™ drivers provided
View full details
More Details
Specifications
Datasheets

The 9810 Series Programmable AC Power Supplies provide 500 VA or 1000 VA output with adjustable voltage (0 to 300 V) and frequency (45 Hz to 500 Hz). These power supplies feature a color 4.3-inch LCD for easy monitoring of AC voltage, current, peak current, power factor, frequency, and crest factor. The 9810 Series supports advanced list mode programming with up to 50 programs and 9 steps per program, and includes surge/dropout functionality for simulating real-world conditions. Built-in protection features safeguard devices under test with overvoltage, overcurrent, overpower, and overtemperature protections. Communication options include USB (VCOM), RS232, and integration with PLC systems via the dedicated REMOTE terminal.

Model No

9814-220V

Condition

New

Manufacturer

BK Precision

BK Precision 9810 Series
