• 659600E Megger Meter
1 1
New
Earn Loyalty with Rewards
Compare

659600E Megger Meter New

659600E Megger Meter New

$1,420
$1,420 $1,420
Shipping calculated at checkout.
Request a Quote
Estimated Delivery in
2-3
business days
Login & Get 2% Back on Purchases
Login or Sign Up for Loyalty

Features:

  • 75 ft. max. height (power application)
  • Dramatically reduces measuring time
  • Inherently safe
  • Designed for ease-of-use
  • Hand-held portability
  • Calibration and maintenance free operation
  • No physical connection to cables or wires
  • Measures the height of up to six overhead cables
View full details
More Details
Specifications
Datasheets

Applications:

The Cable Height Meters are capable of measuring the lowest cable, provided it is within range. Additionally the spacing between the next five cables can be displayed. This is accomplished by standing directly beneath the cable and aligning yourself longitudinally (looking down the line). Simply press the “ON” button to power the instrument up and allow the temperature to stabilize. Press the ‘MEASURE’ button and if necessary gently “rock and tilt” the instrument until a stable reading is obtained. Applications include measuring cable heights of:

  • Telephone lines
  • Distribution lines
  • Transmission lines
  • Cable television (installers and contractors)
  • Street lights
  • Sag (lowest point to ground)
  • Separation between up to six cables

The instrument can be used to ensure that OSHA overhead clearance regulations are met at construction sites. It also provides a safer way to measure cable heights on highly congested roadways. Additionally the Cable Height Meters offer an easy way to check whether the device has remained in calibration since its purchase date. Switching to ‘CAL’ mode also allows the instruments to be used indoors.

Description:

The CHM Series of Cable Height Meters utilize ultrasonic techniques to determine the height of up to six overhead cables and wires. The instruments are designed to address specific measuring requirements on cables up to 75 feet (23 m). The CHM600 (C/N 659600) and CHM600E (C/N 659600E) are designed primarily for power cable applications, while the CHM2000 is designed for telecommunication applications. The Cable Height Meters emit short bursts of sound which originate from the cone shaped transmitter. The microprocessor in the instruments calculates the elapsed time for the bursts of sound to be reflected from the cable back to the instruments. The result can be displayed in either feet and inches or meters. However, before the final measurement can be displayed, the air temperature must be measured because the speed of sound varies at approximately 0.2 percent per degree Celsius. A temperature sensor, mounted at the front of the instruments, senses the actual air temperature. This information is sent to the microprocessor and incorporated into the algorithm. The distance is then displayed in meters or feet and inches depending on which was selected.

Model No

659600E

Condition

New

Manufacturer

Megger

Megger_CHM600_CHM600E_CHM2000
