The Agilent 83732B is a synthesized signal generator covering 10 MHz to 20 GHz, designed for applications requiring precise frequency control combined with comprehensive modulation capabilities. As documented in the datasheet, the 8370B series encompasses four models: the 83711B and 83712B synthesized CW generators, and the 83731B and 83732B synthesized signal generators, which add pulse, AM, FM, and optional phase modulation. The 83732B extends frequency coverage down to 10 MHz, distinguishing it from the 83731B which begins at 1 GHz.

The datasheet specifies the 8370B series for use with the Agilent 8970B noise figure meter through Special Function 41.5, and for driving the Agilent 83550 Series Millimeter Wave Source Modules via the rear-panel 0.5V/GHz output. The instruments are intended for ATE system integration, with SCPI programming compatibility and emulation of Agilent 8673 commands for compatibility with existing automated test systems. The pulse modulation capability of the 83731B and 83732B supports radar simulation and pulse characterization applications.

ValueTronics International stocks and supports the Agilent 8370B series from our 20,000 sq ft secure warehouse at 1675 Cambridge Drive in Elgin, Illinois. Every {{CONDITION}} 83732B that ships from our facility has been inventoried, inspected, and prepared in-house by our technical team — not drop-shipped from a third-party broker. This direct handling means we can verify configuration details, confirm option strings, and answer specific questions about each unit before it leaves our dock.

Brand Heritage

Hewlett-Packard's test and measurement business was spun off as Agilent Technologies in 1999. In 2014, Agilent's electronic measurement business was further separated as Keysight Technologies, which now holds the lineage of HP and Agilent test and measurement instruments including the 8370B series synthesized signal generators.

Compare Other Models in This Series

The Agilent 8370B series comprises four models that share a common synthesizer architecture and chassis platform but differ along two axes: frequency coverage and modulation capability. The 83711B and 83731B cover 1 to 20 GHz, while the 83712B and 83732B extend the low end down to 10 MHz. The 83711B and 83712B are synthesized CW generators, while the 83731B and 83732B add pulse, amplitude, and frequency modulation capabilities as standard features.

All four models share the same frequency resolution (1 kHz standard, 1 Hz with Option 1E8), the same frequency switching speed, the same maximum leveled output power tiers, and the same option set for step attenuator, high-stability timebase, and 3.5 mm RF output connector. The 83731B and 83732B add the Option 1E2 internal modulation generator and Option 800 analog phase modulation as available options not applicable to the CW-only 83711B and 83712B.

Each model in this family is listed as its own product page with pre-owned-matched pricing and inventory. Select the model that matches both the frequency coverage your application requires and the modulation capability your test setup needs.

The 83732B is the broadest-coverage member of the family, providing 10 MHz to 20 GHz frequency range combined with pulse, AM, FM, and optional phase modulation. The datasheet specifies harmonics at less than -55 dBc at output levels below +6 dBm for the 83731B and 83732B, compared to less than -50 dBc for the 83711B and 83712B.

The primary differentiators across the family are frequency coverage and modulation capability. The 83711B and 83731B begin at 1 GHz; the 83712B and 83732B extend down to 10 MHz. The 83711B and 83712B are CW-only synthesized sources; the 83731B and 83732B add comprehensive modulation including pulse modulation with rise and fall times under 10 ns above 1 GHz.

The comparison table that follows summarizes the frequency range, modulation capabilities, and harmonic performance differences across the four models as printed in the datasheet.

Additional differences in specifications beyond the few shown above are not listed here — see each model's full specifications below.

Product Core & Specifications

About this used unit

• Warranty included
• Functional verification included
• Standard Calibration Upgrade Options: No Calibration Required, NIST Traceable, Z540.1 or ISO 17025 with Data, Z540.3 Guardbanding with Data.
• Note that unnecessary accessories may not be included (contact Test Architect to confirm).

Please review the Manufacturer's Data Sheet to verify published specifications. Feedback on this webpage is always welcome — please reach out to your Test Architect at any time for questions or concerns. Thank you, we truly appreciate you being our customer.
